MCX, MMBX & MMCX Connectors
: 7 Products FoundContract pricing display is unavailable at the moment. Prices shown are standard retail prices, orders placed will have contract pricing applied when processed.
Select the properties you would like to see added to the columns at the end of the table.
| Manufacturer Part No | Order Code | Description / Manufacturer | Availability | Price For |
Price Ex. VAT (Inc. VAT)
|
Quantity | Connector Type | Connector Body Style | Coaxial Termination | Impedance | Coaxial Cable Types | Contact Material | Contact Plating | Frequency Max | Connector Mounting | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
37-01M-6-TGG
|
CN14944 |
Plug, MMCX, Straight, Crimp, RG178 MULTICOMP PRO The 37-01M-6-TGG is a crimp MMCX Straight Plug for use with RG178U RF coaxial cables. It has gold-plated brass body with centre contact and a PTFE insulator. • 1.22 Maximum VSWR • -55 to 155°C Operating temperature range • Multicomp Pro products are rated ...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £2.91 (£3.49) 100+ £2.38 (£2.86) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MMCX Coaxial | Straight Plug | Crimp | 50ohm | RG178 | Beryllium Copper | Gold Plated Contacts | 6GHz | Cable Mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
37-01L-5-TGG
|
CN14943 |
Plug, MMCX, Straight, Crimp, RG174 MULTICOMP PRO The 37-01L-5-TGG is a MMCX Straight Plug with gold plated brass contact, gold plated brass body and PTFE insulated as per ASTM D1457 and ASTM D1710 standards. Cable mounting and crimp type termination. This RF/coaxial connector can be used to connect RG-17...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £2.71 (£3.25) 100+ £2.45 (£2.94) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MMCX Coaxial | Straight Plug | Crimp | 50ohm | RG174 | Beryllium Copper | Gold Plated Contacts | 6GHz | Cable Mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
37-05-TGG
|
CN14950 |
Plug, MMCX, PCB Mount MULTICOMP PRO The 37-05-TGG is a MMCX Straight Plug with gold plated brass contact, gold plated brass body and PTFE insulated as per ASTM D1457 and ASTM D1710 standards. PCB mounting and solder type termination. This RF/coaxial connector can be used to connect RG-174 ca...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £1.98 (£2.38) 100+ £1.80 (£2.16) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MMCX Coaxial | Straight Bulkhead Plug | Solder | 50ohm | - | Beryllium Copper | Gold Plated Contacts | 6GHz | PCB Mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MCX1121A1-3GT30G-5-50
|
CN20219 |
RF Coaxial, MCX, Straight Plug, 50 Ohm AMPHENOL The MCX1121A1-3GT30G-5-50 is a straight Crimp Plug with 30µinch gold-plated brass contacts and a PTFE insulation. This MCX series has a 50R impedance structure which operates in a frequency range of up to 6GHz. It is push-on/pull-off mating design facilita...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £2.85 (£3.42) 10+ £2.63 (£3.16) 50+ £2.45 (£2.94) 100+ £2.00 (£2.40) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MCX Coaxial | Straight Plug | Crimp | 50ohm | RG174, RG188A, RG316 | Brass | Gold Plated Contacts | 6GHz | Cable Mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
37-02L-4-TGG
|
CN14947 |
Plug, MMCX, Crimp, Right Angle, RG174 MULTICOMP PRO The 37-02L-4-TGG is a MMCX Right-angle Plug with gold plated brass contact, gold plated brass body and PTFE insulated as per ASTM D1457 and ASTM D1710 standards. Cable mounting and crimp type termination. This RF/coaxial connector can be used to connect RG...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £2.95 (£3.54) 100+ £2.66 (£3.19) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MMCX Coaxial | Right Angle Plug | Crimp | 50ohm | RG174 | Beryllium Copper | Gold Plated Contacts | 6GHz | Cable Mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
27-03M-5 TGG
|
CN15030 |
Plug, MCX, Right Angle, Crimp MULTICOMP PRO MCX Connectors offer a 30 per cent reduction in space over similar MB/SMC types Designed for frequencies up to 6 GHz Typical applications include, GPS, Antenna, Automotive, Instrumentation, and Telecom Push / Pull snap on coupling Ideal for use where siz...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £3.53 (£4.24) 10+ £3.40 (£4.08) 50+ £3.28 (£3.94) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MCX Coaxial | Right Angle Plug | Crimp | 50ohm | RG178, RG196 | Brass | Gold Plated Contacts | 6GHz | Cable Mount | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
MCX6251B1-3GT30G-50
|
CN20221 |
RF Coaxial, MCX, Straight Jack, 50 Ohm AMPHENOL The MCX6251B1-3GT30G-50 is a vertical through-hole MCX Straight Jack made of gold-plated beryllium copper contacts and a PTFE insulator.
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £2.29 (£2.75) 10+ £1.99 (£2.39) 50+ £1.79 (£2.15) 100+ £1.59 (£1.91) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
MCX Coaxial | Straight Jack | Through Hole Vertical | 50ohm | - | Beryllium Copper | Gold Plated Contacts | 6GHz | PCB Mount | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
