Small Signal Diodes

Displaying products for Small Signal Diodes - from our range of leading brand manufacturers.

Zener Diodes

Small Signal Schottky Diodes

Bridge Rectifier Diodes

Small Signal Diodes

Schottky Rectifier Diodes

Open Filters

Manufacturer Part No	Order Code	Description / Manufacturer	Price For	Price Ex. VAT (Inc. VAT)	Quantity	Diode Configuration	Repetitive Peak Reverse Voltage	Average Forward Current	Forward Voltage Max	Reverse Recovery Time	Forward Surge Current	Operating Temperature Max	Diode Case Style	No. of Pins	Diode Mounting	Product Range	Qualification
						Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending
BAV21WS-7-F	SC17787 Data Sheet + RoHS	Small Signal Diode, Switching, Single, 250 V, 200 mA, 1.25 V, 50 ns, 2.5 A DIODES INC. The BAV21WS-7-F is a surface mount Small Signal Switching Diode encapsulated in a moulded plastic case. It has matte tin (lead-free plating) annealed over alloy 42 lead frame terminals. It is ideally suited for automated insertion. It can also be used for ... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.05 (£0.06) 20+ £0.04 (£0.05) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	250V	200mA	1.25V	50ns	2.5A	150°C	SOD-323	2Pins	Surface Mount	BAV21	-
1N4448TR	SC19269 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 200 mA, 1 V, 4 ns, 4 A ONSEMI The 1N4448 is a high conductance fast small Signal Diode. This small signal diode is general usage and suitable for many different applications. • 500mW Power dissipation • 300?C/W Junction-to-ambient thermal resistance You previously purchased this product. View in Order History	Each	5+ £0.12 (£0.14) 10+ £0.07 (£0.08) 100+ £0.03 (£0.04)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	100V	200mA	1V	4ns	4A	175°C	DO-204AH	2Pins	Through Hole	1N4448	-888
1N914	SC08157 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 200 mA, 1 V, 4 ns, 4 A ONSEMI The 1N914 is an axial leaded small signal diode. This diode features unidirectional configuration. • Forward surge current of 4A at pulse width 1μs and 1A at pulse width 1s • Maximum repetitive reverse voltage of 100V • Power dissipation is 500mW • Operati... You previously purchased this product. View in Order History	Each	10+ £0.03 (£0.04) 100+ £0.02 (£0.02) 500+ £0.01 (£0.01)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	Single	100V	200mA	1V	4ns	4A	175°C	DO-35 (DO-204AH)	2Pins	Through Hole	1N914	-888
LL4148+	SC15557 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 150 mA, 2.5 V, 4 ns, 500 mA MULTICOMP PRO • Multicomp Pro products are rated 4.6 out of 5 stars • 12 month limited warranty *view Terms & Conditions for details • 96% of customers would recommend to a friend You previously purchased this product. View in Order History	Each	5+ £0.03 (£0.04) 25+ £0.02 (£0.02) 100+ £0.01 (£0.01)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	100V	150mA	2.5V	4ns	500mA	175°C	SOD-80 (MiniMELF)	2Pins	Surface Mount	-	-
BAT54C	SC11298 Data Sheet + RoHS	Small Signal Diode, 30 V, 200 mA, 320 mV, 5 ns, 600 mA NXP • Repetitive Peak Reverse Voltage : 30V • Average Forward Current : 200mA • Forward Voltage Max : 320mV • Reverse Recovery Time : 5ns • Forward Surge Current : 600mA • Operating Temperature Max : 150°C • Diode Case Style : SOT-23 • No. of Pins : 3Pins • Diode Mounting : Surface Mount You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.03 (£0.04) 25+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	-	30V	200mA	320mV	5ns	600mA	150°C	SOT-23	3Pins	Surface Mount	-	-

BAT54CW	SC11305 Data Sheet + RoHS	Small Signal Diode, 30 V, 200 mA, 320 mV, 5 ns, 600 mA NXP • Repetitive Peak Reverse Voltage : 30V • Average Forward Current : 200mA • Forward Voltage Max : 320mV • Reverse Recovery Time : 5ns • Forward Surge Current : 600mA • Diode Case Style : SOT-323 • No. of Pins : 3Pins • Diode Mounting : Surface Mount You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.03 (£0.04) 25+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	-	30V	200mA	320mV	5ns	600mA	-	SOT-323	3Pins	Surface Mount	-	-

MMSD4148T1G	SC11271 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 200 mA, 1 V, 4 ns, 2 A ONSEMI MMSD4148T1G is a high conductance fast small signal diode suitable for general usage and many different applications. • 400mW power dissipation • 312°C/W junction-to-ambient thermal resistance • 4pF total capacitance You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	10+ £0.04 (£0.05) 100+ £0.02 (£0.02) 1000+ £0.02 (£0.02) 3000+ £0.02 (£0.02)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	Single	100V	200mA	1V	4ns	2A	150°C	SOD-123	2Pins	Surface Mount	MMSD4	-888

MCL4148-TR3	SC11251 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 150 mA, 1 V, 4 ns, 2 A VISHAY The MCL4148 from Vishay is surface mount, small signal fast switching diode. The silicon epitaxial planar diode features unidirectional single configuration, hermetic sealed compact size facilitates space saving on boards. • Automotive grade AEC-Q101 quali... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	10+ £0.018 (£0.02) 250+ £0.016 (£0.02) 1000+ £0.015 (£0.02) 2500+ £0.013 (£0.02)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	Single	100V	150mA	1V	4ns	2A	175°C	MicroMELF	2Pins	Surface Mount	-888	AEC-Q101

BAS85	SC11299 Data Sheet + RoHS	Small Signal Diode, 30 V, 200 mA, 320 mV, 5 A NXP • Repetitive Peak Reverse Voltage : 30V • Average Forward Current : 200mA • Forward Voltage Max : 320mV • Forward Surge Current : 5A • Operating Temperature Max : 125°C • Diode Case Style : SOD-80C • No. of Pins : 2Pins • Diode Mounting : Surface Mount You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.04 (£0.05) 25+ £0.03 (£0.04)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	-	30V	200mA	320mV	-	5A	125°C	SOD-80C	2Pins	Surface Mount	-	-

1N4148 (DO-35)	SC07296 Data Sheet + RoHS	Small Signal Diode, 100 V, 150 mA, 1 V MULTICOMP PRO • Repetitive Peak Reverse Voltage : 100V • Average Forward Current : 150mA • Forward Voltage Max : 1V • No. of Pins : 2Pins You previously purchased this product. View in Order History	Pack of 50	1+ £0.62 (£0.74) 10+ £0.52 (£0.62) 100+ £0.41 (£0.49)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	-	100V	150mA	1V	-	-	-	-	2Pins	-	-	-

LS4148	SC07298 Data Sheet + RoHS	Small Signal Diode, 100 V, 150 mA VISHAY • Repetitive Peak Reverse Voltage : 100V • Average Forward Current : 150mA • No. of Pins : 2Pins You previously purchased this product. View in Order History	Pack of 50	1+ £1.88 (£2.26) 10+ £1.50 (£1.80) 100+ £1.13 (£1.36)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	-	100V	150mA	-	-	-	-	-	2Pins	-	-	-

BAV20	SC07320 Data Sheet + RoHS	Small Signal Diode, Single, 200 V, 250 mA, 1.25 V, 50 ns, 1 A NXP The BAV20 is a general purpose Switching Diode fabricated in planar technology and encapsulated in a hermetically sealed leaded glass SOD27 (DO-35) package. It is used for general purposes in industrial equipment such as oscilloscopes, digital voltmeters a... You previously purchased this product. View in Order History	Each	10+ £0.04 (£0.05) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	Single	200V	250mA	1.25V	50ns	1A	175°C	DO-204AH	2Pins	-	BAV20	-

BAV21	SC07321 Data Sheet + RoHS	Small Signal Diode, Single, 250 V, 250 mA, 1.25 V, 50 ns, 1 A NXP The BAV21 is a Switching Diode fabricated in planar technology, high switching speed and very low capacitance. This switching diode is suitable for general purposes. • 625mA Repetitive peak forward current • 400mW Total power dissipation • 5pF Capacitance You previously purchased this product. View in Order History	Each	10+ £0.05 (£0.06) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	Single	250V	250mA	1.25V	50ns	1A	175°C	DO-204AH	2Pins	-	BAV21	-

1N4148 (DO-35)	SC15554 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 150 mA, 1 V, 4 ns, 2 A MULTICOMP PRO Small signal diode in DO-35 package suitable for general purpose applications. • High speed silicon switching diodes, axial leaded • Hermetically sealed glass with stud on either side of glass passivated chip • Extremely low leakage and very high reliabili... You previously purchased this product. View in Order History	Each	5+ £0.03 (£0.04) 25+ £0.02 (£0.02) 100+ £0.01 (£0.01)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	100V	150mA	1V	4ns	2A	200°C	DO-204AH	2Pins	Through Hole	-	-

1N4148WS	SC15556 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 150 mA, 1 V, 4 ns, 350 mA MULTICOMP PRO Small signal diode in SOD-323 flat lead package suitable for general purpose applications. • Fast switching device (TRR <lt/> 4.0ns) • Very small and thin SMD package • Matte tin (Sn) lead finish You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.04 (£0.05) 25+ £0.03 (£0.04) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	100V	150mA	1V	4ns	350mA	150°C	SOD-323FL	2Pins	Surface Mount	-888	-888

BAV99+	SC15553 Data Sheet + RoHS	Small Signal Diode, Dual Series, 75 V, 200 mA, 1.25 V, 6 ns, 4.5 A MULTICOMP PRO The BAV99 from Multicomp Pro is surface mounted high speed switching diode in SOT-23 package. This is a series pair diode with common cathode and common anode configuration and achieves high current conductivity in small package. Applicable at high speed a... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.05 (£0.06) 25+ £0.04 (£0.05) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Dual Series	75V	200mA	1.25V	6ns	4.5A	150°C	SOT-23	3Pins	Surface Mount	BAV99	-

1N4148W+	SC15555 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 150 mA, 1 V, 4 ns, 2 A MULTICOMP PRO • Small signal fast switching diode in SOD 123 package • Multicomp Pro products are rated 4.6 out of 5 stars • 12 month limited warranty *view Terms & Conditions for details • 96% of customers would recommend to a friend You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.04 (£0.05) 25+ £0.03 (£0.04) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	100V	150mA	1V	4ns	2A	150°C	SOD-123F	2Pins	Surface Mount	-	-

BAS116,215	SC17850 Data Sheet + RoHS	Small Signal Diode, Single, 85 V, 215 mA, 1.25 V, 3 µs, 4 A NEXPERIA The BAS116 is an epitaxial medium-speed Switching Diode with low leakage current, encapsulated in a small SOT23 SMD plastic package. It is used for low leakage current applications in surface mounted circuits. • 3pA Low leakage current (typ.) • 75V Continu... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.07 (£0.08) 20+ £0.05 (£0.06) 100+ £0.03 (£0.04)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	85V	215mA	1.25V	3µs	4A	150°C	SOT-23	3Pins	Surface Mount	BAS116	-888

BAS21LT1G	SC17731 Data Sheet + RoHS	Small Signal High Voltage Diode, Single, 250V, 200mA, 1.25V, 50ns, 625mA, SOT-23, SMD ONSEMI • 250VDC Continuous reverse voltage • AEC-Q101 qualified and PPAP capable • Pb-free, halogen free/BFR free You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.05 (£0.06) 20+ £0.03 (£0.04) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	250V	200mA	1.25V	50ns	625mA	150°C	SOT-23	3Pins	Surface Mount	BAS21	AEC-Q101

BAS21HT1G	SC17737 Data Sheet + RoHS	Small Signal Diode, Single, 250 V, 200 mA, 1 V, 50 ns, 625 mA ONSEMI The BAS21HT1G is a small signal Switching Diode designed for high voltage and high speed switching applications. This device is housed in a SOT-23 surface mount package which is ideal for automated insertion. • 250VDC Continuous reverse voltage • AEC-Q101 ... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.05 (£0.06) 20+ £0.03 (£0.04) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	250V	200mA	1V	50ns	625mA	150°C	SOD-323	2Pins	Surface Mount	BAS21	AEC-Q101

BAS716,115	SC17857 Data Sheet + RoHS	Small Signal Diode, Single, 85 V, 200 mA, 1.25 V, 3 µs, 4 A NEXPERIA The BAS716 is an epitaxial medium-speed Switching Diode with low leakage current and encapsulated in an ultra small SOD523 (SC-79) surface-mounted device (SMD) plastic package. It is used for low leakage current applications in surface-mounted circuits. • ... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.06 (£0.07) 20+ £0.05 (£0.06) 100+ £0.04 (£0.05)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	85V	200mA	1.25V	3µs	4A	150°C	SOD-523	2Pins	Surface Mount	BAS71	-888

MMBD1503A	SC17875 Data Sheet + RoHS	Small Signal Diode, Single Pair Series, 200 V, 200 mA, 1.15 V, 2 A ONSEMI The MMBD1503A is a 3-pin high conductance low leakage Small Signal Diode offers the best available combination of quality. It is a Schottky rectifier that offers high reverse voltage (200V). This product is general usage and suitable for many different app... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.06 (£0.07) 20+ £0.04 (£0.05) 100+ £0.03 (£0.04)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single Pair Series	200V	200mA	1.15V	-999ns	2A	150°C	SOT-23	3Pins	Surface Mount	MMBD1	-888

BAW56	SC17797 Data Sheet + RoHS	Small Signal Diode, Dual Common Anode, 75 V, 300 mA, 1.25 V, 4 ns, 2 A DIODES INC. The BAW56 is a surface mount dual Small Signal Switching Diode encapsulated in a moulded plastic case. It has two diode elements connected in common anode configuration and matte tin (lead-free plating) annealed over alloy 42 lead frame terminals. It is id... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.05 (£0.06) 20+ £0.03 (£0.04) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Dual Common Anode	75V	300mA	1.25V	4ns	2A	150°C	SOT-23	3Pins	Surface Mount	BAW56	-

BAV70W,115	SC17718 Data Sheet + RoHS	Small Signal Diode, Dual Common Cathode, 100 V, 175 mA, 1.25 V, 4 ns, 4 A NEXPERIA The BAV70W,115 is a high-speed Switching Diode encapsulated in a small surface-mounted device (SMD) plastic package. It is used for general purpose switching. • ≤1.5pF Low capacitance Cd • Low leakage current • ≤100V Reverse voltage VR You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	5+ £0.05 (£0.06) 20+ £0.03 (£0.04) 100+ £0.02 (£0.02)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Dual Common Cathode	100V	175mA	1.25V	4ns	4A	150°C	SOT-323	3Pins	Surface Mount	BAV70	-888

1N4149	SC17774 Data Sheet + RoHS	Small Signal Diode, Single, 100 V, 500 mA, 1 V, 4 ns, 4 A ONSEMI The 1N4149 is a 2-pin high conductance fast Small Signal Diode offers the best available combination of quality. It is optimized for energy-efficient designs and offers high reverse voltage (200V). This product is general usage and suitable for many differ... You previously purchased this product. View in Order History	Each	5+ £0.05 (£0.06) 20+ £0.02 (£0.02) 100+ £0.01 (£0.01)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	Single	100V	500mA	1V	4ns	4A	175°C	DO-204AH	2Pins	Through Hole	1N4149	-
