Infrared Receivers
: 11 Products FoundContract pricing display is unavailable at the moment. Prices shown are standard retail prices, orders placed will have contract pricing applied when processed.
Select the properties you would like to see added to the columns at the end of the table.
| Manufacturer Part No | Order Code | Description / Manufacturer | Availability | Price For |
Price Ex. VAT (Inc. VAT)
|
Quantity | Carrier Frequency | IR Receiver Mounting Style | Transmission Range | Remote Control Code | Supply Voltage Max | Automatic Gain Control (AGC) Type | Supply Voltage Min | Detection Threshold / Sensitivity | Directivity | Operating Temperature Min | Operating Temperature Max | Supply Current | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | Sort Acending Sort Decending | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
TSOP4838
|
SC09303 |
Photodiode, IR Receiver, 38kHz VISHAY The TSOP4838 from Vishay is a miniaturized IR receiver module for infrared remote control systems. A PIN diode and a preamplifier are assembled on lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected ...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.66 (£0.79) 10+ £0.58 (£0.70) 50+ £0.55 (£0.66) 100+ £0.48 (£0.58) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
38kHz | Side View Through Hole | 24m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.5V | 0.12mW/m² | 45° | -25°C | 85°C | 800µA | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
TSOP34836
|
SC09301 |
Photodiode, IR Receiver, 36kHz VISHAY The TSOP34836 from Vishay is a miniaturized IR receiver module for infrared remote control systems. A PIN diode and a preamplifier are assembled on lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.83 (£1.00) 10+ £0.70 (£0.84) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
36kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.7V | 0.08mW/m² | 45° | -25°C | 85°C | 450µA | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
TSOP32238
|
SC12402 |
Photodiode, IR Receiver, 38kHz VISHAY The TSOP32238 is a 38kHz Miniaturized IR Receiver Module for infrared remote control systems. A PIN diode and a preamplifier are assembled on lead frame. The demodulated output signal can be directly connected to a microprocessor for decoding. • Very low s...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £1.178 (£1.41) 10+ £1.035 (£1.24) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
38kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.7V | 0.08mW/m² | 45° | -25°C | 85°C | 450µA | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
TSOP4138
|
SC12398 |
Photodiode, IR Receiver, 38kHz VISHAY The TSOP4138 is a 38kHz Miniaturized Receiver Module for infrared remote control systems. A PIN diode and a preamplifier are assembled on a lead frame. The demodulated output signal can be directly connected to a microprocessor for decoding. The receiver m...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.54 (£0.65) 10+ £0.47 (£0.56) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
38kHz | Side View Through Hole | 45m | MCIR, Mitsubishi, RECS-80, r-map, XMP-1, XMP-2 | 5.5V | AGC1 | 2.5V | 0.12mW/m² | 45° | -25°C | 85°C | 950µA | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
TSOP34838
|
SC09302 |
Photodiode, IR Receiver, 38kHz VISHAY The TSOP34838 from Vishay is a miniaturized IR receiver module for infrared remote control systems. A PIN diode and a preamplifier are assembled on lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.85 (£1.02) 10+ £0.80 (£0.96) 50+ £0.77 (£0.92) 100+ £0.67 (£0.80) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
38kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.5V | 0.08mW/m² | 45° | -25°C | 85°C | 450µA | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
TSOP2438
|
SC12395 |
Photodiode, IR Receiver, 38kHz VISHAY The TSOP2438 from Vishay is a miniaturized IR receiver module for remote control systems. A PIN diode and a preamplifier are assembled on lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to a micr...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.84 (£1.01) 10+ £0.44 (£0.53) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
38kHz | Side View Through Hole | 45m | NEC, Sharp, r-step | 5.5V | AGC4 | 4.5V | 0.12mW/m² | 45° | -25°C | 85°C | 950µA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
TSOP4836
|
SC12399 |
Photodiode, IR Receiver, 36kHz VISHAY • IR receiver module for remote control systems • Improved immunity against HF and RF noise • Low supply current • Photo detector and preamplifier in one package • Internal filter for PCM frequency • Supply voltage range from 2.5V to 5.5V • Improved immun...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £1.03 (£1.24) 10+ £0.94 (£1.13) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
36kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.5V | 0.12mW/m² | 45° | -25°C | 85°C | 950µA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
TSOP31256
|
SC09968 |
IR Receiver, 950nm VISHAY The TSOP31256 is a miniaturized IR Receiver Module for infrared remote control systems. A PIN diode and a preamplifier are assembled on a lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to a micr...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.98 (£1.18) 10+ £0.82 (£0.98) 100+ £0.71 (£0.85) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
56kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.5V | 0.12mW/m² | 45° | -25°C | 85°C | 450µA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
TSOP4840
|
SC14451 |
Infrared Receiver, Remote Control, 40 kHz, 45m, 45 °, 5.5 V, 2.5 V, -25 °C VISHAY The TSOP4840 is a 40kHz Miniaturized IR Receiver Module for infrared remote control systems. A PIN diode and a preamplifier are assembled on a lead frame. The demodulated output signal can be directly connected to a microprocessor for decoding. The module ...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.79 (£0.95) 10+ £0.58 (£0.70) 100+ £0.47 (£0.56) 250+ £0.39 (£0.47) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
40kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.5V | 0.12mW/m² | 45° | -25°C | 85°C | 950µA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
TSOP32236
|
SC12405 |
Photodiode, IR Receiver, 36kHz VISHAY The TSOP32236 is a miniaturized IR Receiver Module for infrared remote control systems. A PIN diode and a preamplifier are assembled on a lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to a micr...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.79 (£0.95) 10+ £0.30 (£0.36) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
36kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.7V | 0.08mW/m² | 45° | -25°C | 85°C | 450µA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
TSOP2238
|
SC12396 |
Photodiode, IR Receiver, 38kHz VISHAY The TSOP2238 from Vishay is a miniaturized IR receiver module for remote control systems. A PIN diode and a preamplifier are assembled on lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to a micr...
You previously purchased this product.
View in Order History
|
|
Each
|
1+ £0.65 (£0.78) 10+ £0.60 (£0.72) 50+ £0.55 (£0.66) |
Restricted Item
Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Min: 1
Mult:
1
|
38kHz | Side View Through Hole | 45m | RC-5, RC-6, Panasonic, NEC, Sharp, r-step, Thomson RCA | 5.5V | AGC2 | 2.5V | 0.12mW/m² | 45° | -25°C | 85°C | 950µA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
