Crystals

Find the right crystal oscillator for your circuit from our large selection of oscillators. Choose from crystals with frequencies ranging from 32.768kHz to 50MHz.

Crystal Clears

Resonators

Crystal Storage Boxes

16mhz Crystals

Crystal Boxes

Open Filters

Compare Selected Compare (0)

Sort by

Best Match

Best Match Price: Low to High Price: High to Low Stock: Low to High Stock: High to Low

Extended Attributes Attributes

Add properties to the table

Select the properties you would like to see added to the columns at the end of the table.

Select All

Frequency Nom

Crystal Case

Frequency Stability + / -

Load Capacitance

Frequency Tolerance + / -

Product Range

Operating Temperature Min

Operating Temperature Max

Manufacturer Part No	Order Code	Description / Manufacturer	Price For	Price Ex. VAT (Inc. VAT)	Quantity	Frequency Nom	Crystal Case	Frequency Stability + / -	Load Capacitance	Frequency Tolerance + / -	Product Range	Operating Temperature Min	Operating Temperature Max
						Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending
ABS07-32.768KHZ-6-T	SC18329 Data Sheet + RoHS	32.768kHz Crystal, SMD, 3.2mm x 1.5mm, 6pF, 20ppm ABRACON • Guaranteed ESR of 60kΩ maximum for low power designs • 0.9mm height ideal for high density circuit boards • Seam sealed ceramic package offers excellent environmental & heat resistance • Extended operating temperature of -40°C to +85°C for industrial ap... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.92 (£1.10) 10+ £0.85 (£1.02) 100+ £0.75 (£0.90)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 3.2mm x 1.5mm	-	6pF	20ppm	ABS07	-40°C	85°C
9C-16.000MAAJ-T	SC18273 Data Sheet + RoHS	16MHz Crystal, SMD, 11.4 x 4.35mm, 30ppm, 18pF TXC The 9C-16.000MAAJ-T is a 11.4 x 4.35mm SMD Quartz Crystal with high mass production capability. High frequency pullability and low equivalent series resistance. Frequency range of 3.2 to 90MHz, load capacitance of 18pF and frequency tolerance at ±30ppm. • ... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.32 (£0.38) 10+ £0.26 (£0.31) 100+ £0.21 (£0.25)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	16MHz	SMD, 11.4mm x 4.35mm	30ppm	18pF	30ppm	9C	-20°C	70°C
MH32768B	SC18246 Data Sheet + RoHS	32.768kHz Cylindrical Watch Crystal, 8mm x 3mm, 12.5pF, 20ppm EUROQUARTZ The MH32768B is a 3 x 8mm 20ppm cylindrical Watch Crystal with an excellent shock resistance and environmental capability. The MH32768 series crystal is an industry-standard source of clock signals. • 45kΩ Maximum equivalent series resistance • 0.8pF Typic... You previously purchased this product. View in Order History	Each	1+ £0.67 (£0.80) 10+ £0.35 (£0.42) 100+ £0.32 (£0.38)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	Cylinder Radial, 8mm x 3mm Dia	-	12.5pF	20ppm	MH32768	-40°C	85°C
XRCGB27M120F3M00R0	SC18279 Data Sheet + RoHS	27.12MHz Crystal, SMD, 2mm x 1.6mm, 40ppm, 6pF MURATA XRCGB27M120F3M00R0 is a XRCGB series SMD type crystal unit. It is an ideal for consumer applications such as wireless communications (Wi-Fi/BLE/NFC/Zigbee), wired communications (Ethernet/USB), microcomputers, HDDs/SSDs, PCs, game devices, healthcare equip... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.24 (£0.29) 10+ £0.20 (£0.24) 100+ £0.16 (£0.19)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	27.12MHz	SMD, 2mm x 1.6mm	40ppm	6pF	30ppm	XRCGB	-30°C	85°C
ABM7-8.000MHZ-D2Y-T	SC18290 Data Sheet + RoHS	8MHz Crystal, SMD, 6mm x 3.5mm, 30ppm, 18pF ABRACON The ABM7-8.000MHZ-D2Y-T is a 6.0 x 3.5 x 1.4mm Ceramic SMD Micro Miniature Microprocessor Crystal. 1.4mm in height is suitable for high density circuit boards. • Ceramic Package Assures High Reliability • Superior Heat-resistant Glass Sealing • Wide Operat... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.63 (£0.76) 10+ £0.55 (£0.66) 100+ £0.37 (£0.44)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	8MHz	SMD, 6mm x 3.5mm	30ppm	18pF	20ppm	ABM7	-40°C	85°C

ABM8-25.000MHZ-B2-T	SC18238 Data Sheet + RoHS	25MHz Crystal, SMD, 3.2mm x 2.5mm, 50ppm, 18pF ABRACON ABM8-25.000MHZ-B2-T is a ceramic SMD crystal. Applications include high density applications, modems, communication and test equipment, PMCIA, wireless applications. • 0.80mm max height, 25.000MHz frequency, ±50ppm frequency tolerance • Maximum ESR is 50 o... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.47 (£0.56) 10+ £0.38 (£0.46) 100+ £0.29 (£0.35)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	25MHz	SMD, 3.2mm x 2.5mm	50ppm	18pF	20ppm	ABM8	-20°C	70°C

ABM3B-16.000MHZ-B2-T	SC18236 Data Sheet + RoHS	16MHz Crystal, SMD, 5mm x 3.2mm, 50ppm, 18pF, 20ppm ABRACON The ABM3B-16.000MHZ-B2-T is a 5 x 3.2 x 1.1mm 20ppm surface-mount Crystal features tight stability, ceramic and metal lid assures high precision and reliability. The ABM3B series for use with the cellular telephones, pagers, communication and test equipmen... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.69 (£0.83) 10+ £0.61 (£0.73) 100+ £0.50 (£0.60)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	16MHz	SMD, 5mm x 3.2mm	50ppm	18pF	20ppm	ABM3B	-20°C	70°C

Q13MC30610006 MC-306 32.768KHZ 6.0PF	SC18257 Data Sheet + RoHS	32.768KHz Crystal, SMD, 8mm x 3.8mm, 6pF, 20ppm EPSON The Q13MC30610006 is a 8.0 x 3.8 x 2.54mm SMD kHz Range Crystal Oscillator, 20kHz to 120kHz frequency range and fundamental overtone order. • Ageing ±3ppm Per Year Max • 50kΩ ESR You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.46 (£0.55) 10+ £0.38 (£0.46) 100+ £0.30 (£0.36)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 8mm x 3.8mm	-	6pF	20ppm	MC-306	-40°C	85°C

ABS06-32.768KHZ-9-1-T	SC18326 Data Sheet + RoHS	32.768kHz Crystal, SMD, 2mm x 1.2mm, 9pF, 10ppm ABRACON The ABS06-32.768KHZ-9-1-T is a 2 x 1.2 x 0.6mm 10ppm surface-mount low profile Crystal features ceramic offers excellent environmental and heat resistance ideal for high density circuit boards. The ABS06 series crystal for use with the wireless communicati... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £1.03 (£1.24) 10+ £0.66 (£0.79) 100+ £0.50 (£0.60)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 2mm x 1.2mm	-	9pF	10ppm	ABS06	-40°C	85°C

ABMM2-16.000MHZ-E2-T	SC18292 Data Sheet + RoHS	16MHz Crystal, SMD, 6mm x 3.5mm, 20ppm, 18pF ABRACON The ABMM2-16.000MHZ-E2-T is a 6 x 3.6 x 1.2mm 20ppm ceramic surface-mount low profile Quartz Crystal features seam sealed ceramic assures high reliability and tight tolerance and stability. The ABMM2 series crystal for use with the computers, modems, micro... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.68 (£0.82) 10+ £0.60 (£0.72) 100+ £0.50 (£0.60)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	16MHz	SMD, 6mm x 3.5mm	20ppm	18pF	20ppm	ABMM2	-20°C	70°C

ABM10-166-12.000MHZ-T3	SC18336 Data Sheet + RoHS	12MHz Low Profile Quartz Crystal, SMD, 2.5mm x 2mm, 10ppm, 8pF ABRACON • Optimized for low power consumption, wearables, and IoT applications • Guaranteed low 125Ω ESR ensures operation in power sensitive solutions • 0.50mm max height ideally suited for height constrained designs • Seam sealed for long-term reliability You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.38 (£0.46) 10+ £0.31 (£0.37) 100+ £0.25 (£0.30)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	12MHz	SMD, 2.5mm x 2mm	10ppm	8pF	10ppm	ABM10	-20°C	70°C

ABMM2-25.000MHZ-E2-T	SC18231 Data Sheet + RoHS	25MHz Crystal, SMD, 6mm x 3.5mm, 20 ppm, 18pF, 20ppm ABRACON The ABMM2-25.000MHZ-E2-T is a 6 x 3.6 x 1.2mm 20ppm ceramic surface-mount low profile Quartz Crystal features seam sealed ceramic assures high reliability and tight tolerance and stability. The ABMM2 series crystal for use with the computers, modems, micro... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.63 (£0.76) 10+ £0.53 (£0.64) 100+ £0.40 (£0.48)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	25MHz	SMD, 6mm x 3.5mm	20ppm	18pF	20ppm	ABMM2	-20°C	70°C

ABMM2-12.000MHZ-E2-T	SC18247 Data Sheet + RoHS	12MHz Crystal, SMD, 6mm x 3.5mm, 20ppm, 18pF, 20ppm ABRACON The ABMM2-12.000MHZ-E2-T is a 6 x 3.6 x 1.2mm 20ppm ceramic surface-mount low profile Quartz Crystal features seam sealed ceramic assures high reliability and tight tolerance and stability. The ABMM2 series crystal for use with the computers, modems, micro... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.63 (£0.76) 10+ £0.56 (£0.67) 50+ £0.43 (£0.52)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	12MHz	SMD, 6mm x 3.5mm	20ppm	18pF	20ppm	ABMM2	-20°C	70°C

ABS06-32.768KHZ-1-T	SC18293 Data Sheet + RoHS	32.768kHz Crystal, SMD, 2mm x 1.2mm, 12.5pF, 10ppm ABRACON The ABS06-32.768KHZ-1-T is a 2.0 x 1.2 x 0.6mm SMD Low Profile Crystal Oscillator. Hermetically sealed and not moisture sensitive. • Miniature Size Ideal for High Density Circuit Boards • Ceramic Package Offers Excellent Environmental & Heat Resistance • E... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.71 (£0.85) 10+ £0.65 (£0.78) 100+ £0.59 (£0.71)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 2mm x 1.2mm	-	12.5pF	10ppm	ABS06	-40°C	85°C

ABM8AIG-8.000MHZ-1Z-T	SC18344 Data Sheet + RoHS	SMD Crystal, 8MHz, 3.2mm x 2.5mm, 50ppm, 18pF, 10ppm ABRACON • Suitable for applications such as automotive systems, keyless entry and startup, GPS and navigation, ADAS (Advanced Driver Assistance Systems) etc.. You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.56 (£0.67) 10+ £0.50 (£0.60) 100+ £0.42 (£0.50)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	8MHz	SMD, 3.2mm x 2.5mm	50ppm	18pF	10ppm	ABM8AIG Series	-40°C	125°C

CMR200T32.768KDZB-UT	SC18248 Data Sheet RoHS	32.768kHz Tuning Fork Crystal, SMD, 6mm x 1.9mm Dia, 6pF, 20ppm CITIZEN FINEDEVICE The CMR200T32.768KDZB-UT is a 6 x 1.9mm SMD Tuning Fork Crystal with embossed tape, lead formed, automatic mounting and reflowable type. Load capacitance of 6pF and frequency tolerance at ±20ppm. • Ageing ±3ppm per year (maximum) • Fundamental mode You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.46 (£0.55) 10+ £0.37 (£0.44) 100+ £0.31 (£0.37)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	Cylinder SMD, 6mm x 1.9mm Dia	-	6pF	20ppm	CMR200T	-40°C	85°C

R26-32.768- 12.5	SC18249 Data Sheet + RoHS	32.768KHz Tuning Fork Crystal Oscillator, 6.2mm x 2mm. 12.5pF, 20ppm RALTRON The R26-32.768- 12.5 is a 6 x 2mm Tuning Fork Crystal Oscillator in a small compact size with performance, economy, with excellent shock and environmental characteristics. • Ageing ±3ppm Per Year Max • 500MΩ Insulation Resistance You previously purchased this product. View in Order History	Each	2+ £0.09 (£0.11) 10+ £0.07 (£0.08) 100+ £0.06 (£0.07)	Restricted Item Minimum order of 2 items Multiples of 2 only Please enter a valid quantity Add Min: 2 Mult: 2	32.768kHz	Cylinder Radial, 6.2mm x 2mm Dia	-	12.5pF	20ppm	R26	-20°C	60°C

CFS206-32.768-KDZF-UB	SC18223 Data Sheet RoHS	32.768kHz Tunning Fork Crystal, Cylinder Radial, 6.2mm x 2mm Dia, 12.5pF, 20ppm CITIZEN FINEDEVICE The CFS206 series Tuning Fork Crystal Unit best suited for portable devices with low current consumption. It is used as a clock source in digital equipment. • 70000 Quality factor You previously purchased this product. View in Order History	Each	1+ £0.19 (£0.23) 10+ £0.16 (£0.19) 100+ £0.12 (£0.14)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	Cylinder Radial, 6.2mm x 2mm Dia	-	12.5pF	20ppm	CFS206	-20°C	70°C

CM315 32.768KDZY-UT	SC18300 Data Sheet RoHS	32.768KHz Crystal, SMD, 3.2mm x 1.5mm, 7pF, 20ppm CITIZEN FINEDEVICE The CM315 32.768KDZY-UT is a 3.2 x 1.5mm SMD Tuning Fork Crystal with ceramic package. High-stability assured with tight vacuum sealing, load capacitance of 7pF and frequency tolerance at ±20ppm. • Ageing ±3ppm per year (maximum) • Fundamental mode You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.96 (£1.15) 10+ £0.74 (£0.89) 50+ £0.65 (£0.78)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 3.2mm x 1.5mm	-	7pF	20ppm	CM315	-40°C	85°C

HCM49 24.000MABJ-UT	SC18227 Data Sheet + RoHS	24MHz Crystal, SMD, 11.4mm x 4.65mm, 50ppm, 18pF CITIZEN FINEDEVICE The HCM49 24.000MABJ-UT is a 11.4 x 4.65mm 30 and 50ppm surface-mount Crystal Unit with metal can and high performance with the resistance weld sealing. The HCM49 series crystal features automatic mounting and reflow-able for various applications such as c... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.44 (£0.53) 10+ £0.36 (£0.43) 100+ £0.31 (£0.37)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	24MHz	SMD, 11.4mm x 4.65mm	50ppm	18pF	30ppm	HCM49	-10°C	60°C

CFS206 32.768KDZB-UB	SC18224 Data Sheet RoHS	32.768kHz Crystal, Cylinder Radial, 6.2mm x 2mm Dia, 6pF, 20ppm CITIZEN FINEDEVICE The CFS206 32.768KDZB-UB is a 6.2 x 2mm Cylindrical Type Tuning Fork Crystal Unit. It is best suited for portable devices with low current consumption. Acts as a clock source in digital equipment. • Ageing ±3ppm Per Year Max • 35kΩ ESR You previously purchased this product. View in Order History	Each	1+ £0.19 (£0.23) 10+ £0.16 (£0.19) 100+ £0.12 (£0.14)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	Cylinder Radial, 6.2mm x 2mm Dia	-	6pF	20ppm	CFS206	-20°C	70°C

AS-16.000-18	SC18229 Data Sheet + RoHS	16MHz Crystal, 10.3mm x 5mm, 50ppm, 18pF RALTRON The AS-16.000-18 is a 12 x 4.8 x 3.8mm SMD Microprocessor Crystal, excellent Clock Signal Generator for CPU's. • Extended Industrial Temperature Range • Low Profile Surface Mount • Fundamental or 3rd OT Mode • Ageing ±5ppm Per Year Max You previously purchased this product. View in Order History	Each	1+ £0.14 (£0.17) 10+ £0.11 (£0.13) 100+ £0.09 (£0.11)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	16MHz	Through Hole, 10.3mm x 5mm	50ppm	18pF	30ppm	AS	-20°C	70°C

HCM49 8.000MABJ-UT	SC18228 Data Sheet RoHS	8MHz Crystal, SMD, 11.4mm x 4.65mm, 50ppm, 18pF CITIZEN FINEDEVICE The HCM49 8.000MABJ-UT is a 11.4 x 4.65mm 30 and 50ppm surface-mount Crystal Unit with metal can and high performance with the resistance weld sealing. The HCM49 series crystal features automatic mounting and reflow-able for various applications such as co... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.46 (£0.55) 10+ £0.37 (£0.44) 100+ £0.33 (£0.40)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	8MHz	SMD, 11.4mm x 4.65mm	50ppm	18pF	30ppm	HCM49	-10°C	60°C

CC7V-T1A 32.768KHZ +-20PPM 12.5PF	SC18226 Data Sheet + RoHS	32.768MHz Crystal, SMD, 3.2mm x 1.5mm, 12.5pF, 20ppm MICRO CRYSTAL The CC7V-T1A is a 3.2 x 1.5 x 0.9mm SMD Tuning Fork Crystal. A special crystal manufacturing process is used to achieve improved electrical characteristics and a miniaturized blank size. Ceramic crystal with high stability, low power consumption, high shoc... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.69 (£0.83) 10+ £0.52 (£0.62) 100+ £0.46 (£0.55)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 3.2mm x 1.5mm	-	12.5pF	20ppm	CC7V-T1A	-40°C	85°C

ABS07-32.768KHZ-6-4-T	SC18343 Data Sheet + RoHS	SMD Crystal, 32.768 kHz, 3.2mm x 1.5mm, 6pF, 30ppm ABRACON • Suitable for a wide range of applications such as communication and measuring equipment, commercial and industrial applications, wireless communications etc. You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.99 (£1.19) 10+ £0.91 (£1.09) 100+ £0.79 (£0.95)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	32.768kHz	SMD, 3.2mm x 1.5mm	-	6pF	30ppm	ABS07	-40°C	85°C
