Infrared Emitters

: 11 Products Found

Filter Layout: LEFT

TOP

0 Filter(s) Selected

Products Found Please click the 'Apply Filters' button to update results

Keep applying filters or Show Results Show Results

Apply Filters

Filters

Clear All Filters

Contract pricing display is unavailable at the moment. Prices shown are standard retail prices, orders placed will have contract pricing applied when processed.

Infrared Receivers

Open Filters

Manufacturer Part No	Order Code	Description / Manufacturer	Price For	Price Ex. VAT (Inc. VAT)	Quantity	Peak Wavelength	Angle of Half Intensity	Diode Case Style	Radiant Intensity (Ie)	Rise Time	Fall Time tf	Forward Current If(AV)	Forward Voltage VF Max	Operating Temperature Min	Operating Temperature Max
						Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending
SFH4550	SC12374 Data Sheet + RoHS	5mm High Power Infrared Emitting Diode, 860nm OSRAM The SFH4550 from Osram is a radial leaded high power infrared emitter. This device is used for infrared Illumination for cameras, sensor technology and data transmission. • Standard diode case style of T-1 3/4 (5mm) • Narrow emission angle of ±3° • Very hi... You previously purchased this product. View in Order History	Each (Supplied on Cut Tape)	1+ £0.49 (£0.59) 25+ £0.41 (£0.49) 100+ £0.37 (£0.44)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	860nm	-	T-1 3/4 (5mm)	700mW/Sr	12ns	12ns	100mA	1.5V	-40°C	100°C
SFH4350	SC12373 Data Sheet + RoHS	3mm High Power Infrared Emitter, 850nm OSRAM The SFH4350 from Osram is a radial leaded high power infrared emitter. This device is used for infrared Illumination in CMOS camera, sensor technology and data transmission. • Standard diode case style of T-1 (3mm) • Emission angle of ± 13° • Very high rad... You previously purchased this product. View in Order History	Each	1+ £0.46 (£0.55) 25+ £0.39 (£0.47)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	850nm	-	T-1 (3mm)	70mW/Sr	12ns	12ns	100mA	1.5V	-40°C	100°C
GL4800E0000F	SC12379 Data Sheet RoHS	Infrared Emitting Diode, 950nm SHARP The GL4800E0000F is a side view Infrared Emitting Diode. This diode is plastic moulded with resin lens. It has medium directivity angle and minimum radiant flux. It supports 950nm typical peak emission wavelength. It is suitable for use in optoelectronic s... You previously purchased this product. View in Order History	Each	1+ £0.38 (£0.46) 25+ £0.32 (£0.38) 100+ £0.30 (£0.36)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	950nm	30°	Side Looking	-	-	-	20mA	1.2V	-25°C	85°C
OFL-5102	SC11561 Data Sheet + RoHS	5mm Infrared LED Emitter, 940nm MULTICOMP PRO The OFL-5102 from Multicomp Pro is a radial leaded round infrared LED. • Standard diode case style of T-1 3/4 (5mm) • Forward current (If(AV)) of 20mA • Typical forward voltage of 1.25V at 20mA • Material used is A1GaAs/GaAs • Water clear lens type • Domin... You previously purchased this product. View in Order History	Each	10+ £0.05 (£0.06) 50+ £0.04 (£0.05)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	940nm	10°	T-1 3/4 (5mm)	15mW/Sr	-	-	20mA	1.25V	-25°C	85°C
TSAL6100	SC12368 Data Sheet + RoHS	5mm Infrared Emitting Diode, 940nm VISHAY The TSAL6100 is a 2-pin high power Infrared Emitting Diode in GaAlAs multi quantum well (MQW) technology with high radiant power. It features good spectral matching with Si photodetectors, ±10° angle of half intensity and 940nm peak wavelength. It is suita... You previously purchased this product. View in Order History	Each	5+ £0.29 (£0.35) 25+ £0.28 (£0.34) 100+ £0.19 (£0.23)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	940nm	10°	T-1 3/4 (5mm)	15mW/Sr	800ns	800ns	100mA	2.6V	-40°C	85°C

CQY37N	SC12364 Data Sheet + RoHS	1.8mm Infrared Emitting Diode, 950nm, VISHAY 950nm infrared emitting diode in GaAs suitable for use in radiation source in near infrared range. • Leaded package type • T-¾ package form • High reliability • Angle of half intensity of ±12° • Low forward voltage • Suitable for high pulse current operati... You previously purchased this product. View in Order History	Each	5+ £0.31 (£0.37) 25+ £0.29 (£0.35) 100+ £0.19 (£0.23)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	950nm	12°	T-3/4 (1.8mm)	800mW/Sr	800ns	-	50mA	1.3V	-25°C	85°C

KEL5002A-A	SC12363 Data Sheet RoHS	5mm Infrared Emitter, 940nm, KNOWLEDGE-ON The KEL5002A-A is a GaAlAs Infrared Emitting Diode is designed for high power and low forward voltage applications. This device is optimized for speed and efficiency at emission wavelength 940nm and has a high radiant efficiency over a wide range of forwar... You previously purchased this product. View in Order History	Each	5+ £0.80 (£0.96) 25+ £0.66 (£0.79) 100+ £0.51 (£0.61)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	940nm	10°	T-1 3/4 (5mm)	60mW/Sr	-	-	100mA	1.4V	-25°C	85°C

TSAL4400	SC07711 Data Sheet + RoHS	Infrared Emitter, High Power, 25 °, T-1 (3mm), 100 mA, 1.35 V, 940 nm, 800 ns VISHAY The TSAL4400 is a 940nm Infrared Emitting Diode in GaAlAs multi quantum well (MQW) technology. It is moulded in a blue-grey plastic package. It is suitable for use in infrared remote control units, free air transmission systems, infrared source for optical... You previously purchased this product. View in Order History	Each	5+ £0.40 (£0.48) 25+ £0.36 (£0.43) 100+ £0.22 (£0.26)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	940nm	25°	T-1 (3mm)	15mW/Sr	800ns	800ns	100mA	1.35V	-45°C	85°C

LIR053	SC15466 Data Sheet + RoHS	5mm (T-1) Infrared Emitter, 940nm MULTICOMP PRO The LIR053 from Multicomp Pro is a 5mm round shape through hole infrared LED. This is a high intensity gallium arsenide infrared emitting diodes encapsulated in blue transparent or water clear plastic package in T-1 or T-13/4 individually. It is suitable f... You previously purchased this product. View in Order History	Each	10+ £0.90 (£1.08) 100+ £0.07 (£0.08) 250+ £0.05 (£0.06)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	940nm	16°	T-1 3/4 (5mm)	14mW/Sr	600ns	600ns	20mA	1.4V	-40°C	85°C

LIR034	SC15467 Data Sheet + RoHS	3mm (T-1) Infrared Emitter, 940nm, 36 Degree, 10mW MULTICOMP PRO The LIR034 from Multicomp Pro is a 3mm round shape through hole infrared LED. This is a high intensity gallium arsenide infrared emitting diodes encapsulated in blue transparent or water clear plastic package in T-1 or T-13/4 individually. It is suitable f... You previously purchased this product. View in Order History	Each	10+ £0.08 (£0.10) 100+ £0.06 (£0.07) 250+ £0.04 (£0.05)	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	940nm	36°	T-1 (3mm)	10mW/Sr	600ns	600ns	20mA	1.6V	-40°C	85°C

OFL-3102	SC15900 Data Sheet + RoHS	3mm (T-1) Infrared Emitter, 940nm, MULTICOMP PRO The OFL-3102 is an infrared round Emitter Lamp made of A1GaAs/GaAs construction and water clear lens. It features 940nm peak wavelength, 260°C for 5 seconds lead soldering temperature range and 30° viewing angle. • High radiant intensity • Low forward volt... You previously purchased this product. View in Order History	Each	5+ £0.07 (£0.08) 25+ £0.05 (£0.06) 100+ £0.04 (£0.05)	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	940nm	30°	T-1 (3mm)	14mW/Sr	-	-	20mA	1.25V	-25°C	85°C
